Malossi OIL-SEAL 17x28x5 mm FKM

OIL SEALS

Malossi oil seals are technologically advanced and, despite having been specifically designed for competitions, are also excellent for road use. The oil seal rings, made of the most prestigious of materials used in the area of motor sports that are able to perform even the most severe conditions, are the result of advanced technologies that boast state-of-the-art production standards that are required by Malossi.



Technical specifications

Malossi oil seals include the following design features:

* Being outlined on a case by case basis by our technicians, shapes and profiles are purely indicative and may vary depending on each individual application. The image is included only for illustrative purposes regarding the features Malossi oil seals.

The contact area between the sealing lip and the rotating component that passes through the oil seal hole is the most important and therefore the most protected. The contact between the lip edge and the shaft is guaranteed by the spring and the walls (the membrane and the lip), which ensures that there is interference between the two components that is required for the development of the essential radial force to guarantee an optimal seal. After a brief period of use, the edge of the sealing lip is modified and allows a thin film of fluid to be created between the shaft and the lip which, by preventing direct contact between the two components, facilitates lubrication and prevents oil leakage, exponentially increasing the lifetime of the ring.

The following includes the main features of our oil seals:

1. The main body is made with a special blend of fluorinated elastomer, called FKM, which is one of the most valuable on the market. It has excellent physical properties over a wide range of temperatures (-15°C to +210°C), from a maximum operating speed which can reach 35-40 m/s, and provides infinite immersion resistance in hydrocarbons, a feature that determines the extremely long lifetime of our oil seals
2. Metallic steel insert (reinforcement), in compliance with regulations, which is able to provide the right degree of mechanical strength
3. Stainless steel inner spring that is designed to retain its properties over time



Modellek:

• AEON MOTOR COBRA 50 2T (AT70)
• APRILIA SR 50 2T 1994->
• APRILIA AMICO 50 2T
• APRILIA AREA 51 50 2T LC
• APRILIA GULLIVER 50 2T LC
• APRILIA GULLIVER 50 2T
• APRILIA MOJITO CUSTOM 50 2T
• APRILIA RALLY 50 2T (MINARELLI)
• APRILIA SR NETSCAPER 50 2T LC (MINARELLI)
• APRILIA RALLY 50 2T LC (MINARELLI)
• APRILIA SCARABEO 50 4T (PIAGGIO C373M)
• APRILIA SCARABEO 4V 50 4T euro 2
• APRILIA SCARABEO 50 2T (MINARELLI)
• APRILIA SCARABEO CLASSIC 50 2T euro 4 2018-> (CA91M)
• APRILIA SCARABEO STREET 50 2T (PIAGGIO)
• APRILIA SCARABEO STREET 50 2T euro 4 2018-> (CA91M)
• APRILIA SR RACING 50 2T LC (MINARELLI)
• APRILIA SONIC 50 2T
• APRILIA SONIC 50 2T LC
• APRILIA SPORTCITY ONE 50 4T (PIAGGIO C377M)
• APRILIA SPORTCITY ONE STREET 50 2T euro 2
• APRILIA SR (carb.) 50 2T LC 2004-> (PIAGGIO)
• APRILIA SR 50 2T <-1993
• APRILIA SR R 50 2T LC euro 4 2018-> (PIAGGIO CA81M)
• APRILIA SR R FACTORY 50 2T LC (PIAGGIO C361M)
• APRILIA SR DITECH GP1 50 2T LC (PIAGGIO C361M)
• APRILIA SR REPLICA 50 2T LC <-1999
• APRILIA SR MOTARD 50 2T euro 2
• APRILIA SR R (carb.) 50 2T LC (PIAGGIO)
• APRILIA SR STEALTH 50 2T LC (MINARELLI)
• APRILIA SR WWW 50 2T
• ATALA CAROSELLO 50 2T
• BENELLI 491 SPORT 50 2T LC (MINARELLI)
• BETA ARK 50 2T
• BETA ARK 50 2T LC
• BETA CHRONO 50 2T
• BETA EIKON 50 2T LC
• BENELLI 491 GT 50 2T (MINARELLI)
• BENELLI K2 50 2T
• BENELLI K2 50 2T LC
• BENELLI NAKED 50 2T
• BENELLI PEPE 50 2T
• BETA QUADRA 50 2T
• BETA TEMPO 50 2T
• BSV AX 50
• BSV GZ 50
• DERBI ATLANTIS - BULLET 50 2T 2003->
• DERBI GP1 50 2T LC
• DERBI GP1 OPEN 50 2T LC
• DERBI GP1 REVOLUTION 50 2T LC
• DINLI T.REX 50 2T
• E-TON VIPER RXL 50 2T
• FANTIC BIG WHEEL 50 2T
• GILERA DNA 50 2T LC
• GILERA EASY MOVING 50 2T
• GILERA ICE 50 2T
• GILERA RUNNER PureJet 50 2T LC <-2005
• GILERA RUNNER PureJet 50 2T LC 2006->
• GILERA RUNNER SP 50 2T LC <-2005
• GILERA RUNNER SP 50 2T LC 2006-> (C451M)
• GILERA RUNNER 50 2T LC
• GILERA STORM 50 2T
• GILERA STALKER 50 2T
• GILERA TYPHOON 50 2T
• GILERA TYPHOON X 50 2T
• ITALJET DRAGSTER 50 2T LC
• ITALJET JET SET 50 2T
• ITALJET PISTA 2 50 2T
• ITALJET SCOOP 50 2T
• ITALJET TORPEDO NEW 50 2T
• ITALJET YANKEE 50 2T
• LAVERDA QUASAR 50 2T (AR 03)
• MALAGUTI F10 50 2T
• MALAGUTI F12-PHANTOM 50 2T
• MALAGUTI CENTRO 50 2T
• MALAGUTI CENTRO 50 4T euro 2 (C432M)
• MALAGUTI CIAK 50 2T
• MALAGUTI CIAK MASTER 50 4T euro 2
• MALAGUTI F15 FIREFOX 50 2T LC
• MALAGUTI F12 DIGIT KAT-PHANTOM 50 2T LC
• MALAGUTI F12 DIGIT KAT-PHANTOM 50 2T LC euro 2
• MALAGUTI F12-PHANTOM 50 2T LC
• MALAGUTI F12 R LC 50 2T LC euro 2
• MALAGUTI YESTERDAY 50 2T
• MBK BOOSTER 50 2T euro 0-1
• MBK BOOSTER 50 2T euro 2 (A137E)
• MBK BOOSTER SPIRIT 50 2T euro 0-1
• MBK EVOLIS 50 2T
• MBK FIZZ 50 2T
• MBK FLIPPER 50 2T
• MBK FORTE 50 2T
• MBK HOT CHAMP 50 2T
• MBK MACH G 50 2T
• MBK MACH G 50 2T LC
• MBK BOOSTER NAKED 50 2T euro 2 (A137E)
• MBK NITRO 50 2T LC
• MBK BOOSTER NG 50 2T euro 0-1
• MBK BOOSTER NG 50 2T euro 2 (A137E)
• MBK OVETTO 50 2T
• MBK BOOSTER ROCKET 50 2T euro 0-1
• MBK BOOSTER ROCKET 50 2T euro 2 (A137E)
• MBK SORRISO 50 2T 1996->
• MBK STUNT 50 2T euro 0-1
• MBK STUNT 50 2T euro 2
• MOTRON SYNCRO 50
• MOTRON THUNDER'S 50
• PIAGGIO NRG Power 50 2T LC euro 4 2018->2020 (CA71M)
• PIAGGIO DIESIS 50 2T
• PIAGGIO NRG EXTREME 50 2T
• PIAGGIO NRG EXTREME 50 2T LC
• PIAGGIO FLY 50 2T
• PIAGGIO FLY 50 4T
• PIAGGIO FREE 50 2T
• PIAGGIO LIBERTY 50 2T
• PIAGGIO LIBERTY 50 4T
• PIAGGIO LIBERTY 4V 50 4T euro 2
• PIAGGIO NRG MC2 50 2T LC <-1997
• PIAGGIO NRG MC2 50 2T LC 1998->
• PIAGGIO NRG MC3 Purejet 50 2T LC
• PIAGGIO NRG 50 2T LC
• PIAGGIO NRG MC3 DT 50 2T
• PIAGGIO NRG MC3 DD 50 2T LC
• PIAGGIO NTT 50 2T LC
• PIAGGIO NRG Power DD 50 2T LC
• PIAGGIO NRG Power DT 50 2T (C453M)
• PIAGGIO NRG Power Purejet 50 2T LC
• PIAGGIO QUARTZ 50 2T LC
• PIAGGIO SFERA RESTYLING 50 2T
• PIAGGIO SFERA 50 2T
• PIAGGIO TYPHOON 50 2T 2007->2010
• PIAGGIO TYPHOON 50 2T euro 2 2011->2017 (C421M)
• PIAGGIO TYPHOON 50 2T euro 4 2018-> (CA41M)
• PIAGGIO ZIP Fast Rider 50 2T
• PIAGGIO ZIP 50 2T 2000-> (C25EM)
• PIAGGIO ZIP 50 2T <-1999
• PIAGGIO ZIP 50 4T
• PIAGGIO ZIP SP 50 2T LC 2001->
• PIAGGIO ZIP SP 50 2T LC <-2000
• VESPA ET4 50 4T
• VESPA ET2 50 2T 2000->
• VESPA ET2 50 2T <-1999
• VESPA LX 50 2T
• VESPA LX 50 4T
• VESPA LX 4V 50 4T euro 2
• VESPA Primavera 50 2T euro 2 (C533M)
• VESPA S 50 2T euro 2 (C381M)
• VESPA S 4V 50 4T euro 2 (C386M)
• YAMAHA AEROX 50 2T LC euro 0-1
• YAMAHA AEROX 50 2T LC euro 2
• YAMAHA AXIS 50 2T
• YAMAHA BREEZE 50 2T
• YAMAHA BW'S 50 2T euro 0-1
• YAMAHA BW'S 50 2T euro 2 (A137E)
• YAMAHA BW'S Original/Naked 50 2T euro 2 2010-> (A137E)
• YAMAHA BW'S NG 50 2T euro 0-1
• YAMAHA BW'S NG 50 2T euro 2 (A137E)
• YAMAHA JOG ER 50 2T
• YAMAHA JOG 50 2T
• YAMAHA JOG R 50 2T
• YAMAHA JOGRR 50 2T LC euro 2
• YAMAHA JOG Z 50 2T
• YAMAHA NEO'S 50 2T
• YAMAHA SLIDER 50 2T
• YAMAHA SPY 50 2T
• YAMAHA VINO 50 2T
• YAMAHA WHY 50 2T
• YAMAHA ZEST 50 2T
• YAMAHA ZUMA 50 2T
