Malossi ROLLER CRANKCASE MHR YAMAHA-MINARELLI

New look for our MHR Roller Crankcase, made for Minarelli-Yamaha!

This restyling results in the following innovations:

• Military Green Anodized protective coating
• Milled Malossi MHR Logo
• Machined MHR Lion
• Installed bearing and oil seal for primary shaft



Technical description

Gear-box cover for scooters and Minarelli Yamaha 50 cc engines, designed for racing and for a sport upgrade of standard production scooters.

Malossi, after revisiting the gear box assembly, has reduced friction drastically by replacing the original cover with the gravity cast cover, assembled with special bearings.

This cover, machined with high precision machines, has increased strength and reduced weight and able to withstand very high workloads, typical in racing.

Perfectly interchangeable with the original cover and complete with all necessary bearings and seal, the Roller Crankcase helps reduce friction by 4%.



Technical Characteristics and Components

• Reinforced gear-box cover, gravity-fed permanent mould casted with aluminium-silicon alloy, heat treated.
• Increased secondary shaft bores for two bearings - Two (2) special needle roller bearings - One (1) ball bearing with increased load capacity - One (1) oil seal.



Modellek:

• APRILIA SR 50 2T 1994->
• APRILIA AREA 51 50 2T LC
• APRILIA RALLY 50 2T (MINARELLI)
• APRILIA SR NETSCAPER 50 2T LC (MINARELLI)
• APRILIA RALLY 50 2T LC (MINARELLI)
• APRILIA SCARABEO 50 2T (MINARELLI)
• APRILIA SR RACING 50 2T LC (MINARELLI)
• APRILIA SR 50 2T <-1993
• APRILIA SR REPLICA 50 2T LC <-1999
• APRILIA SR STEALTH 50 2T LC (MINARELLI)
• APRILIA SR WWW 50 2T
• BENELLI 491 SPORT 50 2T LC (MINARELLI)
• BETA ARK 50 2T
• BETA ARK 50 2T LC
• BETA EIKON 50 2T LC
• BENELLI 491 GT 50 2T (MINARELLI)
• BENELLI K2 50 2T
• BENELLI K2 50 2T LC
• BENELLI NAKED 50 2T
• BETA QUADRA 50 2T
• MALAGUTI F12-PHANTOM 50 2T
• MALAGUTI F15 FIREFOX 50 2T LC
• MALAGUTI F12 DIGIT KAT-PHANTOM 50 2T LC
• MALAGUTI F12 DIGIT KAT-PHANTOM 50 2T LC euro 2
• MALAGUTI F12-PHANTOM 50 2T LC
• MALAGUTI F12 R LC 50 2T LC euro 2
• MBK BOOSTER 50 2T euro 0-1
• MBK BOOSTER 50 2T euro 2 (A137E)
• MBK BOOSTER SPIRIT 50 2T euro 0-1
• MBK MACH G 50 2T
• MBK MACH G 50 2T LC
• MBK BOOSTER NAKED 50 2T euro 2 (A137E)
• MBK NITRO 50 2T LC
• MBK BOOSTER NG 50 2T euro 0-1
• MBK BOOSTER NG 50 2T euro 2 (A137E)
• MBK OVETTO 50 2T
• MBK BOOSTER ROCKET 50 2T euro 0-1
• MBK BOOSTER ROCKET 50 2T euro 2 (A137E)
• MBK STUNT 50 2T euro 0-1
• MBK STUNT 50 2T euro 2
• YAMAHA AEROX 50 2T LC euro 0-1
• YAMAHA AEROX 50 2T LC euro 2
• YAMAHA BW'S 50 2T euro 0-1
• YAMAHA BW'S 50 2T euro 2 (A137E)
• YAMAHA BW'S Original/Naked 50 2T euro 2 2010-> (A137E)
• YAMAHA BW'S NG 50 2T euro 0-1
• YAMAHA BW'S NG 50 2T euro 2 (A137E)
• YAMAHA JOG R 50 2T
• YAMAHA JOGRR 50 2T LC euro 2
• YAMAHA NEO'S 50 2T
• YAMAHA SLIDER 50 2T
