Silicon-steel springs with high carbon content. heat-treated. dynamically balanced. kiln painted. designed and calculated for each specific application.
CODE | SPRING SIZES | (K) Spring stiffness |
||
A - Ø | B mm | C - Ø | ||
29 6955.R0 |
45 | 77 | 4 | 9.6k |
29 7009.Y0 |
45 | 77 | 3.9 | 8.4k |
2911388.Y0 |
52.6 | 81 | 4.3 | 7.2k |
29 7047.W0 |
53.1 | 110 | 3.6 | 3.5k |
29 7045.Y0 |
53.5 | 115 | 3.7 | 3.8k |
29 7046.R0 |
53.7 | 110 | 3.9 | 4.7k |
2912658.W0 |
57.5 | 105.5 | 4 | 4.2k |
2918843.R0 |
57.5 | 115 | 4 | 4.3k |
29 7042.Y0 |
57.8 | 90 | 4.1 | 6.1k |
29 7043.R0 |
57.8 | 90 | 4.2 | 6.8k |
29 8323.G0 |
57.8 | 91 | 3.9 | 4.9k |
29 8324.V0 |
57.8 | 91 | 4 | 5.5k |
29 8325.A0 |
57.8 | 91 | 4.1 | 5.5k |
2916111.B0 |
57.8 | 103 | 4 | 6k |
29 8360.W0 |
57.8 | 118 | 4 | 3.3k |
29 7077.Y0 |
61.6 | 138 | 3.9 | 2.4k |
29 7087.R0 |
61.8 | 138 | 4 | 2.6k |
Modellek:
- APRILIA MOJITO CUSTOM 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SCARABEO 50 4T (PIAGGIO C373M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SCARABEO 4V 50 4T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SCARABEO CLASSIC 50 2T euro 4 2018-> (CA91M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SCARABEO STREET 50 2T (PIAGGIO) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SCARABEO STREET 50 2T euro 4 2018-> (CA91M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SPORTCITY ONE 50 4T (PIAGGIO C377M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SPORTCITY ONE STREET 50 2T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SR (carb.) 50 2T LC 2004-> (PIAGGIO) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SR R 50 2T LC euro 4 2018-> (PIAGGIO CA81M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SR R FACTORY 50 2T LC (PIAGGIO C361M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SR DITECH GP1 50 2T LC (PIAGGIO C361M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SR MOTARD 50 2T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SR MOTARD 50 2T euro 4 2018-> (CA41M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SR R (carb.) 50 2T LC (PIAGGIO) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SR Street 50 2T LC euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- APRILIA SXR 50 ie 4T euro 5 2021-> (CD32M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- DERBI ATLANTIS - BULLET 50 2T 2003-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- DERBI GP1 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- DERBI GP1 OPEN 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- DERBI GP1 REVOLUTION 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- DERBI VARIANT Sport 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA DNA 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA EASY MOVING 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA ICE 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA RUNNER PureJet 50 2T LC <-2005 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA RUNNER PureJet 50 2T LC 2006-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA RUNNER SP 50 2T LC <-2005 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA RUNNER SP 50 2T LC 2006-> (C451M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA RUNNER 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA STORM 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA STALKER 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA TYPHOON 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- GILERA TYPHOON X 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- ITALJET JET SET 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- ITALJET TORPEDO 50 4T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- ITALJET TORPEDO NEW 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- KYMCO K 12 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- KYMCO AGILITY R16 50 2T euro 2 (KF10B) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- KYMCO AGILITY R16 + 50 2T euro 2 2016-> (KF10D) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- KYMCO DINK 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- KYMCO PEOPLE 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- KYMCO SUPER 9 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- KYMCO TOP BOY - COBRA 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- MALAGUTI CENTRO 50 4T euro 2 (C432M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- MALAGUTI CIAK MASTER 50 4T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- MBK BOOSTER 50 2T euro 2 (A137E) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- MBK BOOSTER NAKED 50 2T euro 2 (A137E) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- MBK BOOSTER NG 50 2T euro 2 (A137E) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- MBK BOOSTER ROCKET 50 2T euro 2 (A137E) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- MBK STUNT 50 2T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG Power 50 2T LC euro 4 2018->2020 (CA71M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO DIESIS 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG EXTREME 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG EXTREME 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO FLY 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO FLY 50 4T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NEW FLY 4V 50 4T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO FREE 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO LIBERTY 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO LIBERTY iGet 50 ie 4T euro 3 2016->2017 (C541M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO LIBERTY iGet 50 ie 4T euro 4 2018->2020 (CA11M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO LIBERTY 3V iGet 50 ie 4T euro 5 2021-> (CD11M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO LIBERTY 50 4T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO LIBERTY 4V 50 4T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG MC2 50 2T LC <-1997 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG MC2 50 2T LC 1998-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG MC3 Purejet 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG MC3 DT 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG MC3 DD 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NTT 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG Power DD 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG Power DT 50 2T (C453M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO NRG Power Purejet 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO QUARTZ 50 2T LC (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO SFERA RESTYLING 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO ZIP S 3V iGet 50 ie 4T euro 5 2021-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO TYPHOON 50 2T 2007->2010 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO TYPHOON 50 2T euro 2 2011->2017 (C421M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO TYPHOON 50 2T euro 4 2018-> (CA41M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO ZIP Fast Rider 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO ZIP 50 2T 2000-> (C25EM) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO ZIP 3V iGet 50 ie 4T euro 4 2018->2020 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO ZIP 3V iGet 50 ie 4T euro 5 2021-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO ZIP 50 4T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO ZIP SP 50 2T LC 2001-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- PIAGGIO ZIP SP 50 2T LC <-2000 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA ET4 50 4T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA ET2 50 2T 2000-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA ET2 50 2T <-1999 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA LX 50 2T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA LX 50 4T (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA LX 4V 50 4T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Primavera 3V iGet 50 ie 4T euro 4 2018->2020 (CA03M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Primavera 3V iGet 50 ie 4T euro 5 2021->2023 (CD01M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Primavera 50 2T euro 2 (C533M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Primavera 4V 50 4T euro 2 (C532M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA S 50 2T euro 2 (C381M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA S 4V 50 4T euro 2 (C386M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA SPRINT 3V IGet 50 ie 4T euro 4 2018->2020 (CA01M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA SPRINT 3V IGet 50 ie 4T euro 5 2021->2023 (CD01M) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Sprint 50 2T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Sprint 4V 50 4T euro 2 (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- YAMAHA BW'S 50 2T euro 2 (A137E) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- YAMAHA BW'S Original/Naked 50 2T euro 2 2010-> (A137E) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- YAMAHA BW'S NG 50 2T euro 2 (A137E) (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Sprint S 3V Iget 50 ie 4T euro 5 2024-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Primavera 3V Iget 50 ie 4T euro 5 2024-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Primavera S 3V Iget 50 ie 4T euro 5 2024-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
- VESPA Primavera Tech 3V Iget 50 ie 4T euro 5 2024-> (for Multivar and original variator - rigidity increase compared to original spring: +30%)
